Product Features
▲ Electronic/magnetic spring type, precise positioning, fast speed, shock resistance, and vibration resistance;
▲ Cable strengthening and optimization, anti bending enhancement;
▲ Enhanced and optimized protection level, with excellent waterproof and oil resistant properties;
▲ Optimized shell material, high strength, and secure fixation;
▲NPN/PNP, automatic detection switching output (more intelligent);
▲ The leakage current is extremely low, only 0.05mA, and multiple switches are connected in parallel without affecting normal operation;
▲ Action magnetic field range of 40-800 Gauss, sensitive and error free (1 action);
▲ Induction for optimal adjustment, accurate movement, and prevention of misoperation caused by magnetic field interference around the cylinder;
| product name | Electronic magnetic switch | |
| model | Two Line Model | NPN three wire PNP three wire |
| Induction switch form | Contactless | Non contact NPN/PNP type |
| Sensitivity of induction | 40-800 Gauss | 40-800 Gauss |
| supply voltage | 10V~28VDC | 5V~30V DC |
| Maximum switch current | 25mA~100mA | 30V/200mA Max. |
| Maximum contact capacitance | 2.8W Max. | 6.0W Max. |
| Internal consumption current | 3mA Max | 5mA Max. |
| Internal residual voltage | 2.7V Max. | 0.7V Max. |
| Pull leakage current | 0.05mA Max. | 0.01mA Max. |
| Maximum switching frequency | 1000Hz | |
| Impact resistance | 50G | |
| Vibration | 9G | |
| Protection circuit | Power polarity reverse protection, surge absorption protection | |
| operation temperature | -10℃~70℃ | |
| protection grade | General type: IP64 Waterproof type: IP68 | |
| pilot lamp | red led | |
| Cable line | 2.8 §, 3C, gray oil resistant PVC | |
| product name | Spring type magnetic switch | |
| model | Two line general type | Two line high-temperature type |
| Induction switch form | There are contacts | |
| Sensitivity of induction | 60-800 Gauss | |
| supply voltage | 10V~240V AC/DC | |
| Maximum switch current | 100mA | |
| Maximum contact capacitance | 10W Max. | |
| Internal consumption current | not have | |
| Internal residual voltage | 2.5V Max.@100mA | not have |
| Pull leakage current | not have | |
| Maximum switching frequency | 200Hz | |
| Impact resistance | 50G | |
| Vibration | 9G | |
| Protection circuit | not have | |
| operation temperature | -10℃~70℃ | |
| protection grade | IP64 | |
| pilot lamp | red led | |
| Cable line | 2.8 §, 3C, gray oil resistant PVC | |
Note:
1. Measurement using standard magnet: § 15.5x § 8x5t (anisotropic plastic magnet), equivalent to measuring the sensing surface below the switch;
2. Sine wave/X, Y, Z3 axial/3 cycles (each direction)/11ms (each cycle);
3. Complex amplitude of 1.5mm/10Hz-55Hz-10Hz (reciprocating for 1 minute)/X, Y, Z3 axis/1 hour (per cycle);
|
